Angular contact ball bearings

Trans Power angular contact ball bearings are designed to handle both radial and axial loads simultaneously, making them essential for high-precision, high-speed applications. Built with optimized contact angles and durable materials, they deliver consistent performance under demanding operating conditions.

Send email to us Download as PDF

Product Detail

Product Tags

Products Description

Angular Contact Ball Bearings (ACBB) are engineered to handle combined radial and axial loads simultaneously with exceptional precision. Featuring a defined contact angle (typically 15°-40°), they deliver superior rigidity, high-speed capability, and accurate shaft positioning – making them critical for applications demanding minimal deflection and maximum rotational accuracy.

TP’s ACBB series combines advanced materials, optimized internal geometry, and ISO-certified manufacturing to ensure unmatched performance in industrial automation, robotics, machine tools, and high-performance drivetrains.

Angular Contact Ball Bearings Type

Types	Features
Single-Row Angular Contact Ball Bearings	Designed to accommodate combined radial and axial loads in one direction. Common contact angles: 15°, 25°, 30°, 40°. Often used in paired arrangements (back-to-back, face-to-face, tandem) for higher load capacity or bidirectional load handling. Typical Models: 70xx, 72xx, 73xx series.
Double-Row Angular Contact Ball Bearings	Functionally similar to two single-row bearings mounted back-to-back. Can support axial loads in both directions along with radial loads. High rigidity and space-saving design. Typical Models: 32xx, 33xx series.
Matched Angular Contact Ball Bearings	Two or more single-row bearings assembled together with specific preload. Arrangements include: DB (Back-to-back) – for moment load resistance DF (Face-to-face) – for shaft alignment tolerance DT (Tandem) – for high axial load in one direction Used in precision machine tools, motors, and spindles.
Four-Point-Contact Ball Bearings	Designed to handle axial loads in both directions and limited radial loads. Inner ring split into two halves to allow four-point contact. Common in gearboxes, pumps, and aerospace applications. Typical Models: QJ2xx, QJ3xx series.
